Module Parameters

1

Model

G10.41

2

Pitch(mm)

P10.41

3

Transparency（%）

83

4

Pixel Configuration

1R1G1B

5

LED Type

SMD3506

6

Driving IC

MBI/SUM IC, high refresh with blanking

7

Working Voltage（DC）

4.5V

8

Life Time

100,000 House

9

Scanning

1/3

Cabinet Parameters

1

Size(mm)

1000X1000*80

2

Resolution(pixels)

96*96

3

Structure Material

Die Cast Aluminum + Aluminum

4

Weight(kg)

9.6

5

Pixel Density(Pixels/Cabinet)

9216

6

Brightness(NIT)

≥4000

7

Grey Grade(BIT)

13

8

Colors（Trillion）

0.55

9

Contrast

3000：1

10

Fresh Frequency(Hz)

≥1920

11

Transparency

82％

12

Protection Grade

IP30

13

MPC/APC(W/Cabinet)

800/300

14

Input Voltage

110-240 V

15

Working Temperature

-10℃～40℃

16

Working Humidity

10%RH～95%RH

17

Best Viewing Disctance(m)

≥12

18

Installation Way

Stacked, Hanging, fixed installation

19

Service Way

Front or Back

Screen Parameters

1

Pixel Density(Pixels/ m²)

9216

2

MPC/APC (W/ m²)

800/300

3

Signal Port

DVI、HDMI、DP

4

Control System

Linsn/Nova
