Brand: Vista
Pixel pitch: 6.4mm,8mm,10.66mm,16mm
Environment: Outdoor Fixed installation
Pixel configuration: 1R1G1B SMD3535/DIP346
Cabinet size: 1024x1024x120mm
Brightness: 6500nits
Parameters
Value
Pitch
6.4mm
8mm
10.66mm
16mm
Brightness
5000cd/㎡
5500cd/㎡
7500cd/㎡
8000cd/㎡
LED type
SMD2727
SMD3535
Scanning
5 Scanning
4 Scanning
Static
Pixel Density
Cabinet Resolution
24336 dots/㎡
15625 dots/㎡
8836 dots/㎡
3906 dots/㎡
160*160
128*128
96*96
64*64
Viewing Angle
H:160 V:90 H:160 V:90 H :140 V :90 H :140 V :90
IP rating
IP65
MPC
450W/sqm
300W/sqm
180W/sqm
APC
200W/sqm
120W/sqm
80W/sqm
Voltage
200-240V/50-60Hz
Cabinet Dimensions(mm)
1024x1024x127 1024x1024x137
Cabinet Dimensions(feet)
3.4*3.4
Weight
30KG 35KG
Grey Grade
14bit
Fresh Frequency
1920hz
4320hz
Cabinet material
Aluminum
Working temperature
-20 - 50 ℃
Store Humidity
10 - 90%
Certification
CCC(S&E)、RoHS
