Your Location: Home > Products > Advertising LED Display > Outdoor LED Totem Display

Product Number: Outdoor Totem

Brand: Vista

Pixel pitch: 2.5mm, 3mm, 4mm, 5mm,6mm

Environment: outdoor

Pixel configuration: 1R1G1B SMD3535/SMD1921

Cabinet size: 116", 93", 79", 65" （ ok for customized size, usually 1m x 2m around）

Brightness: 1200 nits/6500 nits

Views:

Features

Specification

Cases

Enquiry

Model		Outdoor Totem Series-P4		Outdoor Totem Series-P5		Outdoor Totem Series-P6
Display	Pixel Pitch	4mm		5mm		6mm
	Display(inch)	93	76	93	76	93	76
	Dimensions(mm)	14002800200	11602430200	14002800200	11602430200	14002800200	11602430200
	Display(mm)	1200*2040	960*1680	1200*2040	960*1680	1200*2040	960*1680
	Resolution	300*510	240*420	240*408	192*336	200*340	160*280
Parameter	Brightness(cd/m²)	≥6500		≥6500		≥6500
	Bright	Auto/Manual		Auto/Manual		Auto/Manual
	Viewing Angle(degree)	H:V (140,140)		H:V (140,140)		H:V (140,140)
	Contrast	2000:1		2000:1		2000:1
	Drive	Dynamic Scanning
	Refresh Rate(Hz)	1920		1920		1920
	Frame(Hz)	60		60		60
	Grey Scale(Bit)	14		14		14
	Viewing distance(M)	>4		>5		>6
Parameter	Voltage(V)	AC110/220 +15%
	AP(W/m²)	250		250		250
	MP(W/m2)	650		650		650
	Maintenance	Front&Back service
	IP grade	IP67
	Condition(/%RH)	-35~+60/10~95
	Lifespan(H)	50000
	Communication	3G/Wifi/Lan/USB drive
Material	Aluminium frame+Stailess Steel base + Front tempered glass
